5mm-120mm Wear Resistant Steel Plate ASTM DIN High Mechanical Strength
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Length | Wear Resistant Steel | Grade | Nm400 |
|---|---|---|---|
| Standard List | AiSi, ASTM, Bs, DIN, GB, JIS | Product Name | Nm400 Wear Resistant Steel Plate |
| Material | Wear Resistant Plate ASTM | Delivery Time | 16 Working Days |
| Highlight | 5mm Wear Resistant Steel Plate,Wear Resistant Steel Plate ASTM DIN,ASTM DIN wear resistant wear plate |
||
Product Description
Nm400 Wear Resistant Steel Plate
NM400 Wear Resistant Steel Plate
NM400 is high strength wear resistant steel plate. The NM400 has quite high mechanical strength; Its mechanical properties are 3 times to 5 times that of ordinary low alloy steel plates. It can significantly improve the wear resistance of mechanical related parts. Therefore, improve the service life of machinery; The surface hardness of the product usually reaches 360 ~ 450HB. Used for mining and all kinds of construction machinery wear-resistant parts processing and manufacturing applicable structural steel plate.
- Grade: NM400
- Type: High strength wear resistant steel plate
- Application: Construction machinery, mining machinery, etc
- Name source: “Nai” and “grinding” Chinese pinyin first letter, 400 is the Brinell hardness value HB value
NM400 Wear Resistant Steel Plate Definition
NM400 is a kind of wear-resistant steel plate. NM – represents wear-resistant use of “resistant” and “grinding” Chinese pinyin first letter 400 is the Brinell hardness value HB value. (The hardness value of 400 is generalized, and the hardness value range of domestic NM400 is 360-420.)
NM400 wear-resistant steel plate is widely used in construction machinery, mining machinery, coal mining machinery, environmental protection machinery, metallurgical machinery and other parts. Excavator, loader, bulldozer bucket board, blade board, side blade board, blade. Crusher lining plate, blade.
The delivery status of wear-resistant steel plate is: quenching and tempering (that is, quenching and tempering)
Thickness: 5mm-120mm(optional).
Width: 500mm-4000mm(optional).
Length: 1000mm-12000mm(optional).
Profiled: According to drawing.
Inspection: Chemical analysis, Metallographic, Mechnical analysis, Ultrasonic testing, Impact testing, Hardness testing, Surface quality and Dimension report.
MOQ: 1pcs.
Technical data
NM400 Chemical Component
| Element | C | Si | Mn | P | S | Cr | Mo | Ni | B | CEV | |
| Grade | NM400 | ≤0.25 | ≤0.70 | ≤1.60 | ≤0.025 | ≤0.010 | ≤1.4 | ≤0.50 | ≤1.00 | ≤0.004 |
NM400 Mechanical Properties
| Steel Grade | Y.S (MPa) | T.S (MPa) | Elongation A5(%) | Impact Test | Hardness | |
| min | min | min | (°C) | AKV J(min) | HBW | |
| NM360 | 800 | 1000 | 10 | -20 | 30 | 320-400 |
| NM400 | 1000 | 1250 | 10 | -20 | 30 | 360-440 |
| NM450 | 1250 | 1500 | 10 | -20 | 30 | 410-490 |
| NM500 | 1300 | 1700 | 10 | -20 | 30 | 450-540 |
