Food Industry 304 Seamless Stainless Steel Tubing 0.25mm-3.0mm Thickness
| Place of Origin | China |
|---|---|
| Brand Name | HNJBL |
| Certification | BV,SGS |
| Model Number | 304 |
| Minimum Order Quantity | 1ton |
| Price | Negotiate |
| Packaging Details | Waterproof Paper, Steel Strip Packed and other Standard Export Seaworthy Package, or customized package |
| Delivery Time | 5-25working days |
| Payment Terms | L/C, T/T, D/A |
| Supply Ability | 10000ton/month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Names | 304 Stainless Steel Pipe | Corrosion Resistance | Wet Resistance |
|---|---|---|---|
| Standard | ASTM JIS | Delivery Time | 5-28days |
| Steel Grade/Type | 310s | Lengths Range | 6m, 12m,18m |
| Highlight | Seamless Stainless Steel Tubing 0.25mm,Food Industry Seamless Stainless Steel Tubing,304 Stainless Steel Tube 3.0mm |
||
Product Description
16 FAQ about 304 stainless steel tubes:
What is 304 stainless steel?
304 stainless steel is a type of austenitic stainless steel that contains chromium and nickel, which provides excellent corrosion resistance and high-temperature strength.
What are the advantages of using 304 stainless steel tubes?
304 stainless steel tubes have excellent corrosion resistance, high-temperature resistance, and good mechanical properties.
What are the applications of 304 stainless steel tubes?
304 stainless steel tubes are widely used in industries such as chemical, petrochemical, pharmaceutical, food processing, and marine.
What is the difference between 304 and 316 stainless steel tubes?
316 stainless steel tubes have higher corrosion resistance than 304 stainless steel tubes, especially in environments containing chlorides. They also have higher strength and hardness.
What is the maximum temperature that 304 stainless steel tubes can withstand?
304 stainless steel tubes can withstand temperatures up to 1700°F (927°C).
What is the minimum temperature that 304 stainless steel tubes can withstand?
304 stainless steel tubes can withstand temperatures as low as -425°F (-254°C).
What is the maximum pressure that 304 stainless steel tubes can withstand?
The maximum pressure that 304 stainless steel tubes can withstand depends on the size, wall thickness, and temperature of the tubes. Generally, they can withstand pressures up to 1000 psi.
What is the minimum pressure that 304 stainless steel tubes can withstand?
304 stainless steel tubes can withstand very low pressures, such as those found in vacuum systems.
What are the different finishes available for 304 stainless steel tubes?
The different finishes available for 304 stainless steel tubes include brushed, mirror, satin, and matte.
What are the different grades of 304 stainless steel tubes?
There are several grades of 304 stainless steel tubes, including 304L, 304H, and 304LN, which have different chemical compositions and properties.
What are the different standards for 304 stainless steel tubes?
The different standards for 304 stainless steel tubes include ASTM A269, ASTM A213, and EN 10216-5, which specify the requirements for the manufacturing, testing, and quality control of the tubes.
What is the weight of 304 stainless steel tubes?
The weight of 304 stainless steel tubes depends on the size, wall thickness, and length of the tubes. A 1-inch diameter tube with a wall thickness of 0.065 inches and a length of 10 feet weighs approximately 2.5 pounds.
What is the density of 304 stainless steel tubes?
The density of 304 stainless steel is approximately 8.03 g/cm³.
What is the tensile strength of 304 stainless steel tubes?
The tensile strength of 304 stainless steel tubes is approximately 515 MPa.
What is the yield strength of 304 stainless steel tubes?
The yield strength of 304 stainless steel tubes is approximately 205 MPa.
What is the corrosion resistance of 304 stainless steel tubes?
304 stainless steel tubes have excellent corrosion resistance to a wide range of chemicals and environments, including acids, alkalis, and chlorides.
|
Standard |
ASTM, AISI, GB, JIS, customers' requests available |
| Size | Round Tube: OD: 16-119mm or customized |
| Thickness | 0.25mm-3.0mm |
| Length | 6m or according to customers' request |
| Sample | Free sample is available, but freight should be paid by you |
|
Tolerance
|
Outer diameter: ±0.2mm |
| Thickness: ±0.05mm | |
| Length: ±0.5mm | |
| Ends | In plain end or bevelled ends or as your requirements |
| Welding Line Type | ERW (Electrical Resistance Weld) |
|
Finishing
|
A. Sanded |
| B. Gloss #400,Mirror #600 - #1000 | |
| C. Brushed | |
| D. Wood Grain | |
| E. Embossed, Threaded | |
| Application | Decorations, constructions, food industry, etc. |
| Certification | ISO, SGS |
| Round Pipe Size | 16, 17, 18, 19, 20, 21, 22, 23, 25, 28, 31.8, 35, 36, 38.1, 48, 50.8, 60, 63.5, 76.2, 89, 101, 114 mm |
| Square Pipe Size | 17, 18, 19, 20, 21, 22, 23, 24, 25, 28, 30, 36, 38, 50 mm |
| Rectangle Pipe Size | 10*30, 10*40, 10*50, 20*10, 23*11, 24*12, 25*13, 28*25, 28*13, 29*14, 30*15, 30*20, 30*22, 34*22, 36*23, 50*25, 60*30, 75*45, 95*45 mm |
| Thickness | exact 0.25, 0.28, 0.32, 0.37, 0.41, 0.51, 0.61, 0.71, 0.91, 1.11, 1.15, 1.41 mm |
| Length | 6m or according to customer’s request |
| Outer diameter | 6.35-219mm |
| Tolerance | Outer diameter :±0.2mm |
| Thickness :±0.02mm | |
| Length :±0.5mm | |
| Process method | Code drawn, annealed with nitrogen protection, ultrasonic, automatic shape, polished |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine Sand-blasting machine, etc |
| Origin | West Europe / Japanese / Indian / USA / Korean / American / European |
| Test Certificates | Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report |
|
Grade
|
C
|
Cr
|
Ni
|
Mo
|
Other
|
|
301
|
≤0.15
|
16.0~18.0
|
6.00~8.00
|
-
|
-
|
|
301L
|
≤0.030
|
16.0~18.0
|
6.00~8.00
|
-
|
N≤0.20
|
|
304
|
≤0.08
|
18.0~20.0
|
8.00~10.50
|
-
|
-
|
|
304J1
|
0.02~0.05
|
16.5~17.1
|
7.5~7.9
|
-
|
Cu1.9~2.2
|
|
304L
|
≤0.030
|
18.0~20.0
|
9.00~13.00
|
-
|
-
|
|
304N1
|
≤0.08
|
18.0~20.0
|
7.00~10.50
|
-
|
N0.10~ 0.25
|
|
304N2
|
≤0.08
|
18.0~20.0
|
7.50~10.50
|
-
|
Nb≤0.15
|
|
316
|
≤0.08
|
16.0~18.0
|
10.00~14.00
|
2.00~3.00
|
-
|
|
316L
|
≤0.03
|
16.0~18.0
|
12.00~15.00
|
-
|
-
|
|
321
|
≤0.08
|
17.0~19.0
|
9.00~13.00
|
-
|
Ti5×C%
|
|
409L
|
≤0.03
|
17.0~19.0
|
-
|
-
|
Ti6×C%~0.75
|
|
410L
|
≤0.03
|
11.0~13.5
|
-
|
-
|
-
|
|
430
|
≤0.12
|
16.0~18.0
|
-
|
-
|
-
|
|
430J1L
|
≤0.025
|
16.0~20.0
|
-
|
-
|
Nb8(C%+N%)~0.8
Cu0.30~0.80 |
|
436L
|
≤0.025
|
16.0~19.0
|
-
|
0.75~1.25
|
Ti,Nb,Zr8
×(C%+N%)~0.8 |
|
410
|
≤0.15
|
11.5~13.5
|
-
|
-
|
-
|
|
420J1
|
0.16~0.25
|
12.0~14.0
|
-
|
-
|
-
|
|
420J2
|
0.26~0.4
|
12.0~14.0
|
-
|
-
|
-
|
|
2205
|
0.38~0.43
|
21~23
|
4.5~6.5
|
2.5~3.5
|
-
|
|
2507
|
≤0.03
|
24.0~26.0
|
6.00~8.00
|
3.0~5.0
|
-
|
Surface Finish
|
Surface finish
|
Characteristics & Application
|
|
NO.1
|
Hot-rolled surface, annealed and pickled, can be used as cold-rolling material,industial tanks and chem i cal devices.
|
|
NO.2D
|
Cold-rolled, an nealed and pick led with out skinpassing the dull prod ucts can be used as auto mo bile parts, build ing materrials and pipings.
|
|
NO.2B
|
The surface brightness and flatness of NO.2B is better than NO.2D. Then through a special surfacetreament to improve its mechamical properties, N02B could nearly satisfy com pre hen sive uses.
|
|
NO.3
|
Polished with abra sive belt of grit #100#120,have bet ter bright ness with dis con tin u ous coarse stria, used as in ner and ex ter nal or na ments for building, elec tri cal ap pli anc es and kitchen uten sils etc.
|
|
NO.4
|
Polished with abrasive belt of grit #150#180, have better brightness with discontinuous coarse stria, but thinner than NO.3, are used as bathtud buildinginner and external ornaments electrical appliances, kitchen utensils and food processing equipment etc.
|
|
HL
|
Polished with abrasive belt of grit #150-320 on the No.4 finish and has continuous streaks, mainly used as building ornaments, elevators, door of building, frontal plate etc.
|
|
BA
|
Cold rolled, bright an nealed and skin passed, the prod uct has ex cel lent bright ness and good re flex iv i ty like mirror, used for lectrical appliances, mirror, kitch en apparatus, or na ment ma te ri als etc.
|
Product Applications
Good weldability and flame cutting, nonmagnetic. The shipbuilding industry, welded constructions.
Physical properties (average values) at ambient temperature
Modulus of elasticity [103 x N/mm2]: 210
Density [g/cm3]: Approx. 7.80
Solution Annealing
Harden from a temperature of 1000-1050oC followed by water quenching.
.
Product show
Manufacturing Technique
Certificate
Package and Delivery
|
Package
|
Standard export seaworthy package,suit for all kinds of transport, or as required.
|
|
Water-proof Paper + Edge protection + Wooden Pallets
|
|
|
Bulk Size
|
Any size
|
|
Loading Port
|
Tianjin, Xingang Port, Qingdao,Shanghai, Ningbo, or any China Seaport
|
|
Container
|
1*20ft container load Max. 25 Ton, Max. length 5.8m
|
|
1*40ft container load Max. 25 Ton, Max. Length 11.8m
|
|
|
Delivery Time
|
7-15 days or according to the order's quantity
|
Duplex Stainless Steel Pipes and Tubes Applications
The Duplex Stainless Steel Pipes and Tubes are used in the following applications:-
- Chemical Processing, Transport, and Storage
- Oil and Gas Exploration and Offshore Rigs
- Mil and Gas Refining
- Marine Environments
- Pollution Control Equipment
- Pulp & Paper Manufacturing
- Chemical Process Plant
FAQ
Q. Are you a factory or trading company?
A. We are a factory company.
Q. What is the MOQ?
A. Sample order is acceptable, And some samples can be free.
Q3. How do you control quality?
A3: Mill Test Certification is supplied with shipment, Third Party Inspection is available.
Q. How many countries have you already exported?
A: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt,Turkey, Jordan, India, etc.
Q. How do you resolve the problem with your products?
A. Person of aging services: For customer complaints commissioner set up special complaint handling, complaint issues recorded the the first time, and find the relevant person in charge of the feedback and resolution. Details check our "Quality corrective action report"
Q. How long do you need the delivery time?
1)Supply within 5-10days (product in our stock list)
2)Custom products need to be calculated according to the quantity
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.
Q.How can we get your price?
A. We need the below information to quote for you:
1. Product Name
2. Standard
3. Material Grade (Chemical Composition)
4. Dimension
5. Quantity
6. The Drawing for Special Parts
