1mm~22mm 317LMN Stainless Steel Sheet Plate High tensile Strength
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | 317LMN Stainless Sheet Metal | Material | 317LMN Stainless Steel Plate |
|---|---|---|---|
| Surface | 2B NO.2 No.4 No.6 | Third Party | SGS BV |
| Width | 1000-2200mm Or As Requirements | Thickness | 1mm~22mm |
| Highlight | 22mm 317LMN Stainless Steel Sheet,22mm 317LMN Stainless Steel Plate,317LMN Stainless Steel Sheet High Strength |
||
Product Description
what is 317LMNStainless Steel Plate
317LMN steel plate is a high-strength austenitic stainless steel that is commonly used in the food and beverage processing, pharmaceutical, and chemical industries. It is highly resistant to corrosion and heat, making it an ideal choice for applications that require a durable material. It is also non-magnetic and non-toxic, making it safe for use in food processing and other applications. It can be used in a variety of applications, including storage tanks, piping, pressure vessels, and other structural components.
what are the differences between 317LMN stainless steel and 316 stainless steel
The primary difference between 317LMN stainless steel and 316 stainless steel is that 317LMN stainless steel is an austenitic steel grade, while 316 stainless steel is a ferritic steel grade. 317LMN stainless steel is higher in molybdenum content than 316 stainless steel, which increases its corrosion resistance in certain environments. Additionally, 317LMN stainless steel has higher levels of nitrogen and lower levels of carbon than 316 stainless steel, which gives it a higher tensile strength.
Chemical Composition (%) of 317LMN Stainless Steel Plate
| Carbon | Silicon | Sulfur | Phosphorus | Chromium | Molybdenum | Manganese | Nickel | Nitrogen |
| 0.030 | 0.75 | 0.030 | 0.045 | 17.0-20.0 | 4.0-5.0 | 2.00 | 13.5-17.5 | 0.10-0.20 |
Mechanical Properties of 317LMN Stainless Steel Plate
| Yield Strength 0.2% Offset |
Ultimate Tensile Strength |
Elongation in 2 in. |
Hardness | ||
| psi (min.) | (MPa) | psi (min.) | (MPa) | % (min.) | (max.) |
| 30,000 | 205 | 80,000 | 550 | 40 | 96 Rockwell B |
Physical Properties of 317LMN Stainless Steel Plate
| Density lb/inᶟ | 0.290 |
| Density g/cmᶟ | 8.0 |
| Melting Range | 2540-2630°F/1393 – 1443 °C |
| Thermal Conductivity at 212°F (100°C) | 8.7 BTU/hr/ft²/ft/°F |
| Thermal Conductivity at 212°F (100°C) | 1.26 W/m-°K |
| Electrical Resistivity | 33.5 Microhm-in at 68°C |
| Electrical Resistivity | 85.1 Microhm-cm at 20°C |
About us
Packing & Delivery
Packing Details : Export standard package,bundled or be required.
The inner size of container is below:
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high)
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high)
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high)
Delivery Details : 7-15 days or according to the order quantity or upon negotiation
