SGS 317/317l Stainless Steel Sheet Plate Customized Width wear resistance
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | 317 Stainless Sheet Metal | Material | 317/317L Stainless Steel Plate |
|---|---|---|---|
| Surface | 2B NO.2 No.4 | Third Party | SGS BV |
| Width | 1000-2200mm Or As Requirements | Thickness | 1mm~22mm |
| Highlight | SGS 317l Stainless Steel Sheet,SGS 317l stainless steel plate,317l Stainless Steel Sheet wear resistance |
||
Product Description
what is 317/317L Stainless Steel Plate
317/317L Stainless Steel Plate is a chromium-nickel molybdenum alloy stainless steel plate. It is a higher-end version of 316 stainless steel and has improved corrosion resistance due to its higher molybdenum content. It is also more resistant to pitting and crevice corrosion than 316 stainless steel.
317 stainless steel plates are often used for applications that require superior corrosion resistance, such as in chemical processing, petrochemical, and marine applications. Compared to 316 stainless steel, 317 stainless steel offers higher creep, stress-to-rupture, and tensile strength at elevated temperatures. Additionally, 317 stainless steel has higher chloride ion corrosion resistance than 316 stainless steel, making it especially resistant to pitting and crevice corrosion in chloride environments.
317 Stainless Steel Plate Range
Chemical Composition (%) of 317/317L Stainless Steel Plate
| Carbon | Silicon | Sulfur | Phosphorus | Chromium | Molybdenum | Manganese | Nickel | Nitrogen |
| 0.030 | 0.75 | 0.030 | 0.045 | 18.0-20.0 | 3.0-4.0 | 2.00 | 11.0-15.0 | 0.10 |
Mechanical Properties of 317/317L Stainless Steel Plate
| Yield Strengtd 0.2% Offset |
Ultimate Tensile Strength |
Elongation in 2 in. |
Hardness | ||
| psi (min.) | (MPa) | psi (min.) | (MPa) | % (min.) | (max.) |
| 30,000 | 205 | 75,000 | 515 | 40 | 95 Rockwell B |
Physical Properties of 317/317L Stainless Steel Plate
| Density lb/inᶟ | 0.285 |
| Density g/cmᶟ | 7.89 |
| Melting Range | 2540-2630°F/1390 – 1440 °C |
| Thermal Conductivity at 212°F (100°C) | 8.7 BTU/hr/ft²/ft/°F |
| Thermal Conductivity at 212°F (100°C) | 1.26 W/m-°K |
| Electrical Resistivity | 33.5 Microhm-in at 68°C |
| Electrical Resistivity | 85.1 Microhm-cm at 20°C |
About us
Packing & Delivery
Packing Details : Export standard package,bundled or be required.
The inner size of container is below:
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high)
40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high)
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high)
Delivery Details : 7-15 days or according to the order quantity or upon negotiation
Q: What the main products you can supply?
A: We are a professional and famous factory in China for Stainles steel sheets/ Coils/ Tubes/ Profiles/Composite packaging Materials; Corten steel; Wear Resistant steel and Carton steels.
Q: Will you accept customized and OEM products?
A: Yes, we can do the production based on your drawings and with your logo, also because we have a very strong design and development team, so the feedback is very good for customized products.
Q: What are your payment terms?
A: Commonly two payment terms for new customers
1 ) 30%T/T as deposit,70% balance against B/L copy. 2)100% Irrevocable L/C at sight.
If you need other terms, please feel free to contact us too, we will try our best.
